Product overview:
Sequential simulated moving bed chromatographic separation technology (SSMB), is based on different substances in the system composed of stationary phase and mobile phase have different distribution coefficient, in the use of mobile phase elution process presents different retention time, so as to realize separation. Traditional chromatographic separation technology uses fixed chromatographic column, first into a certain amount of material, and then use eluent to continuously elute, in the same outlet in different time periods can receive different product components, this process is time-consuming and laborious. After analysis and improvement, We make the Resin of stationary phase into a continuous flow system, and realize separation by using the difference of relative motion speed between material and stationary phase.

At present, the continuous chromatographic separation technology has achieved mature industrialization. In addition to the actual moving bed, there is another simulated moving bed that can be applied. At present, the industrial SSMB system of our company adopts an electromagnetic valve group to simulate the actual switching effect of the Resin column of the moving bed, i.e. the Resin column does not move, while the inlet and outlet are controlled by the program valve to open or close the inlet and outlet to the corresponding Resin column.

Product Features

the consumption of Resin is obviously reduced;

improve the yield, purity and concentration of the product (countercurrent flow, Resin column series, and combination);

Extended service life of the Resin (shallow contamination);

Reduction of water and chemical consumption (30-70% savings), reduction of sewage discharge;

Compact equipment, small floor space, fully automatic operation.
